Product Description:
Kingway has a wide range of option of top quality and factory price explosion proof generator. We're a leading company in this industry, we provide various generator sets for farms and agricultural industry, data centers, hospitals, manufacturing centers, quarries, mines, telecommunications and other application. The explosion-proof motor has a structure that is different from that used in ordinary environments. It can prevent the combustible gas and dust outside the motor from entering the motor to the maximum extent. Ignite the combustible gas and dust existing in the surrounding environment outside the casing. We also supply 3 Phase Gas Generator and clip on generator.
|
Equipment |
150KVA Explosion-proof Diesel Engine Genset |
|
Directive |
2014/34/UE-ATEX |
|
Standard |
EN 60079 series / EN 1834 series / EN 1755 |
|
Convert to |
Group II Equipment, Category 3G ( ZONE 2 IIB T3 Gc ) |
ATEX explosion proof Zone 2 Generator for applications in Hazardous Area ( Zone 2 ) mounted in the DNV certified 2.7-1 Skid frame enclosure producing 150KVA @ 0.8 pf,400VAC, 3 Phase +Neutral, 50HZ Output
|
MODEL |
EADG150-EX2 |
|
COMPLETE MACHINE |
|
|
Explosion-proof Mark |
#II 3G IIB T3 Gc |
|
Hazardous Zone |
ZONE 2 |
|
Certificate |
1.ATEX Certificate for engine |
|
Typical generating set output (0.8 pf 25ºC) |
150KVA 50HZ |
|
Max. Working Angle |
15° |
|
Noise Sound Level (±5 dBA at 7m) |
85 |
|
Machine Weight (kg) |
2800 (dry) for reference only |
|
Dimensions: L x W x H mm |
3000X2200X2000 for reference only |
|
Fuel tank |
>300L |
|
DIESEL ENGINE |
|
|
Manufacturer |
CUMMINS |
|
Model |
6BTAA5.9-G12 |
|
Governed Speed (rpm) |
1500 |
|
Original Genset Prime Power (kW) |
150KVA@1500rpm |
|
Displacement (L) |
5.9L |
|
No. of cylinders |
6 |
|
Electrical System Voltage (V) |
24 |
|
Rated Capacity of Battery |
130Ah |
|
GENERATORS |
|
|
Manufacturer |
Kingway OEM |
|
Explosion-proof Mark |
# II 3G Ex nA IIB T3 IP55 |
|
Certificate number |
《Declaration of conformity》 |
|
Hazardous Zone |
ZONE 2 |
|
Ambient temperature |
-25℃~ +60℃ |
|
Altitude |
≤1000M |
|
Rated Voltage |
400V |
|
Rated Frequency |
50HZ |
|
Rated REV |
1500RPM |
|
Power Factor |
0.8 LAG |
|
Operation |
Continuous (S1) |
|
IP Grade |
IP55 |
|
Controller |
ComAp brand |
