Product Description
Supported by high-quality LED light source, it has both energy-saving and durability, with sufficient luminous efficiency and uniform light. Matching with a vertical manual operation mast, it is easy to use, with moderate lighting height and flexible rotation angle, effectively covering the lighting area. It has good wind resistance, suitable for mild outdoor operation environments, and the parking brake device ensures towing safety. The standard traction interface can be compatible with various traction equipment; optional dedicated generator is available, with quiet operation and long endurance. The packaging combining carton and wooden pallet is convenient for batch storage and transportation, suitable for various scenarios such as small outdoor engineering and temporary lighting, with convenient installation and strong practicality.
Technical Parameters
|
Parameter Category |
Detailed Specifications |
|
Product Model |
SL-L1200G |
|
Light Type |
LED Lamp |
|
Light Power |
300W x 4 |
|
Luminous Flux |
120000 Lm |
|
Mast Type |
Vertical Manual |
|
Lighting Height |
5 m |
|
Rotation Angle |
36° |
|
Max Wind Speed |
50 Km/h |
|
Towing Speed |
5 Km/h |
|
Brake System |
Parking Brake |
|
Tire Size |
12 inch |
|
Towing Coupling |
Standard Coupling |
|
Min Dimension |
1370x880x1950 mm |
|
Max Dimension |
1770x1500x5030 mm |
|
Package Dimension |
1530x960x642 mm |
|
Product Weight |
173 Kg |
|
Loading Capacity |
21units/60units |
|
Optional Generator |
DG8500SE |
|
Engine Model |
D500E/Diesel |
|
Cooling System |
Air Cooled |
|
Engine Speed |
3000/3600 rpm |
|
Generator Power |
5.5 Kw |
|
Voltage/Phase |
230V/1P (Single Phase) |
|
Current |
23.9 A |
|
Fuel Tank Capacity |
13 L |
|
Running Time |
12 h (75% Load) |
|
Noise Level |
62 dBa@7m |
|
Packaging |
Carton + Wooden Pallet |
Application Scope
Widely used in construction sites, mining areas, emergency rescue, outdoor events, ports, remote areas, security patrol, night construction and other outdoor scenarios that require temporary or long-term lighting.
Why Choose Us
•Professional manufacturer with rich experience in outdoor lighting equipment production.
•Strict quality control, reliable product quality, compliant with international standards.
•Perfect after-sales service and technical support, solving problems in time.
•Fast delivery, supporting various transportation methods to meet different needs.
Packaging & Delivery
Packaging: Standard export packaging, anti-collision and anti-moisture, ensuring product safety during transportation.
Delivery Time: Fast delivery according to stock and order quantity.
Transportation: Support sea, air and land transportation, safe and efficient.
Contact Us
If you are interested in our products, please feel free to contact us for quotation and more details. We will reply to you as soon as possible and provide professional solutions.
